Specifications

Features

  • Suitable for 1.6mm (16ga) C Series straight brads
  • Full range of 19mm to 65mm in electro galvanized and stainless steel finish
  • Best in class ergonomics – optimised balance to maximise comfort and reduce fatigue
  • New lightweight design reduces end user fatigue over periods of extended use
  • New oil free design allows for maintenance free operation
  • New rear exhaust vents air out the back of handle and away from user
  • New No Mar Tip design improves line of sight offers precise brad location
  • New extended reach trigger allows for greater operation in high and hard to reach places
  • Selectable trigger offering bump fire or sequential option
  • Adjustable depth of drive provides greater flexibility for nail placement and a superior finish
  • Quick clear nose provides less downtime if a nail jam does occur
  • Reversible belt hook secures tool to apron effortlessly
  • Nail lock out eliminates blank firing protecting timber and tool

Previous models

Specifications
Product CodeB20160
Weight1.8kg
Fastener Range19 – 65mm
Operating Pressure 550 – 830kpa (80 – 120psi)
Dimensions (L x H x W)314 x 295 x 74mm
Air Consumption0.99 litres @ 690kpa
Collation Angle
Magazine Capacity100 approx
Applications
Architraves
Quads
Beading
Stair Rails
Mouldings
Skirting Boards
Panelling
Door Stop

Featured Video

How to maintain the Paslode Pneumatic Framer

This video shows best practice for caring for your Paslode Pneumatic framing nailer.

Watch Our Videos On YouTube

For more tips, customer stories and product-specific videos visit our YouTube channel via the button below.

Fastener Charts

Nails Compatible with Paslode Pneumatic T250-16S C Bradder

Here’s a list of recommended fasteners to use with your Paslode Paslode Pneumatic T250-16S C Bradder.

Note: Electro Galvanised brads for internal use only.

Fasteners

Product CodeBrad (Gauge)LengthFinishHeadBox Qty
B20219C Series (16ga)19mmElectro GalvLost3000
B20225C Series (16ga)25mmElectro GalvLost3000
B20280C Series (16ga)25mmStainless steelLost2000
B20232C Series (16ga)32mmElectro GalvLost3000
B20238C Series (16ga)38mmElectro GalvLost3000
B20285C Series (16ga)38mmStainless steelLost2000
B20245C Series (16ga)45mmElectro GalvLost3000
B20250C Series (16ga)50mmElectro GalvLost3000
B20290C Series (16ga)50mmStainless steelLost2000
B20265C Series (16ga)65mmElectro GalvLost3000
